AFR1500
VPC Pneumatic
8421399000
Working medium: | |
---|---|
Mounting Type: | |
Working temperature: | |
Working pressure: | |
Assembly Position: | |
Precision: | |
Availability: | |
Product Description
Guaranteed pressure resistance | 1.5Mpa |
Max working pressure | 1.0Mpa |
Working temperature | 5-60℃ |
Filter Precision | 25um(5um is optional) |
Bowl material | Polycarbonate |
Pressure adjusting range | AC1000:0.05-0.7Mpa AC2000:0.05-0.85Mpa |
Valve type | With overflow |
Model | Specification | Accessories | Drian Function | Auto drain model | |||
Rated flow(L/min) | Port size(G) | Pressure gauge thread size(G) | Weight(kg) | Bracket (2pcs) | |||
AFR1500 | 550 | G1/8" | 1/8 | 0.36 | B220 | Manual drain | AFR2000D |
AFR2000 | G1/4" | AFR2000D |
