■ Specifications
| Model | AC20A-B | AC30A-B | AC40A-B | AC40-06-B | AC50A-B | AC60A-B |
| Component | Filter Regulator [AW] | AW20-B | AW30-B | AW40-B | AW40-06-B | AW50-B | AW60-B |
| Lubricator [AL] | AL20-A | AL30-A | AL40-A | AL40-06-A | AL50-A | AL60-A |
| Port size | 1/8, 1/4 | 1/4, 3/8 | 1/4, 3/8, 1/2 | 3/4 | 3/4, 1 | 1 |
| Pressure gauge port size *1) [AW] | 1/8
|
| Working medium | Clean Air |
| Working temperature*2) | -5 to 60°C (No freezing) |
| Proof pressure | 1.5Mpa
|
| Max. Working pressure | 1.0Mpa |
| Set pressure range [AW] | 0.05 to 0.85Mpa |
| Nominal filtration rating [AW] | 5 µm |
| Recommended lubricant [AL] | Class 1 turbine oil (ISO VG32) |
| Bowl material [AW/AL] | Polycarbonate |
| Bowl guard [AW/AL] | Semi-standard (Steel) | Standard (Polycarbonate) |
| Construction [AW] | Relieving type |
*1) Pressure gauge connection threads are not available for F.R.L. unit with a square embedded type pressure gauge or with a digital pressure switch.
*2) -5 to 50°C for the products with the digital pressure switch.
