1. Quick and reliable mounting clamps makes it convenient to install and use.
2. The performance of pressure adjustment is reliable with high precision.
3. The efficiency of eliminating moisture and solid grain is high.
4. Two drain types are available: semi-auto drain and automatic drain.
5. Three material of bowl are available: PC, Nylon and metal.

  • BFC

  • VPC Pneumatic

  • 8412909000

Working medium:
Air
Working temperature:
5~60 ℃
Working pressure:
0.5~8.5bar
Quality Warranty:
1year
Availability:
Inquire Add to Basket

Product Specifications

ModelAFC1500AFC2000BFC2000BFC3000BFC4000
Working mediumCompressed Air
Port sizeG1/8G1/4G1/4G3/8G1/2
Filter precision25um(5/40 um is optional)
Adjusting pressure range0.05~0.85Mpa
Max. Adjusting pressure0.95Mpa
Guaranteed. pressure1.5Mpa
Working temperature5~60°C
Filter bowl capacity15(CC)60(CC)
Lubricator bowl capacity25(CC)90(CC)
Recommended OilISO VG32 or equivalent Oil
Weight0.7kg0.9kg


Components

Filter Regulator
AFR1500AFR2000BFR2000BFR3000BFR4000
LubricatorAL1500AL2000BL2000BL3000BL4000


Main Dimensions
