PM
VPC Pneumatic
39174000
Thread: | |
---|---|
Body Material: | |
Quality Warranty: | |
Availability: | |
Product Description
■ Features
ㆍSafety Coupling with self-venting mechanism;
ㆍNo whiplash effect due to the self-venting which takes place during disconnection;
ㆍ Compact & robust design due to the hardened valve body.
ㆍLow connection forces
■ Applications
ㆍPneumatic Tools;
ㆍPneumatic Airline Systems;
ㆍAssembly Lines.
Product Specifications
Model | PM-20 | PM-30 | PM-40 | PM-400 | PM-600 | PM-800 |
Size | 1/4" Tube | 3/8" Tube | 1/2" Tube | 1/2" Tube | 3/4" Tube | 1" Tube |
Working Medium | Water or Air | |||||
Working Pressure Range | 0 to 150Psi | |||||
Working Temperature Range | -20 to 107℃(-4F to 225F) | |||||
Air Flow | 35 SCFM at 100 PSIG inlet with 10 PSIG pressure drop | |||||
Tube Material | Nylon, PU Tube, PA Hose, etc |
