| Working medium: | |
|---|---|
| Working pressure: | |
| Max pressure: | |
| Working temperature: | |
| Stations No: | |
Product Description
1. Centralized piping reduces leakage and maintenance time.
2. Modular expansion to support system upgrades.
3. High-quality surface treatment enhances durability in industrial environments.
4. Compatible with ISO-standard pneumatic solenoid valves.
5. Suitable for high-cycle applications in automation lines.
Product Specifications
| Model | 100 Series | 200 Series | 300 Series | 400 Series |
| Working medium | Clean air (40 um Filteration) | |||
| Working pressure | 0.15 to 0.9 Mpa | |||
| Max.pressure | 1.5 Mpa | |||
| Working temperature | -20 to 70 ℃ | |||
| Application scope | 4V100 Series 4A100 Series | 4V200 Series 4A200 Series | 4V300 Series 4A300 Series | 4V400 Series 4A400 Series |
| Valve model | 4V110/4V120/4V130 4A110/4A120/4A130 | 4V210/4V220/4V230 4A210/4A220/4A230 | 4V310/4V320/4V330 4A310/4A320/4A330 | 4V410/4V420/4V430 4A410/4A420/4A430 |
| Manifold model | 100M-NF(N≤16) | 200M-NF(N≤16) | 300M-NF(N≤12) | 400M-NF(N≤7) |
